Geoflow Geocomposites

Geoflow is a high performance geocomposite for drainage and gas management applications.

Geoflow consists of a biaxial geonet manufactured from high density polyethylene heat bonded to a polypropylene nonwoven geotextile fabric available in either a single or double-sided configuration. The geonet provides a flow path for liquid and gases and the geotextile acts as a filter and separator, keeping soil and or waste particles out of the geonet drainage core.

Features & Benefits

  • Geoflow has multiple functions as a drainage, venting, leak detection and or protection layer
  • Cost effective solution compared to conventional aggregate drainage layers
  • Suitable for vertical and horizontal applications
  • Excellent chemical resistance
  • Excellent durability and long-term performance
  • High transmissivity
  • High compressive strength
  • Increases landfill capacity
  • Flexible, lightweight and easy to install
  • Wide roll widths for efficient installation

General Areas of Application

Landfill

  • Leak detection system for double and single liners
  • Leachate collection and drainage
  • Gas collection system for capping
  • Landfill capping surface water drainage

Wastewater/Dairy Effluent

  • Leak detection
  • Under liner drainage
  • Gas venting

Vertical Drainage

  • Behind retaining walls
  • Basement walls
  • Foundations
  • Tunnels

Horizontal Drainage

  • Under liner system roof gardens
  • Under pavers
  • Parking decks
  • Foundation gas barrier venting

Roading & Rail

  • Drainage of embankments
  • Road base
  • Railway track bed
